WIVO VALVES Electric Cast Iron Knife Gate Valve
  • WIVO VALVES Electric Cast Iron Knife Gate ValveWIVO VALVES Electric Cast Iron Knife Gate Valve

WIVO VALVES Electric Cast Iron Knife Gate Valve

WIVO VALVES presents a high-performance electric actuated cast iron knife gate valve, designed for demanding industrial applications where reliable shut-off of abrasive, viscous, or slurry media is required. The DN200 (8-inch) model WKGE-200-E combines rugged construction with advanced automation capabilities, making it ideal for wastewater treatment, mining, pulp & paper, chemical processing, and power plants.

WIVO VALVES presents a high-performance electric actuated cast iron knife gate valve, designed for demanding industrial applications where reliable shut-off of abrasive, viscous, or slurry media is required. The DN200 (8-inch) model WKGE-200-E combines rugged construction with advanced automation capabilities, making it ideal for wastewater treatment, mining, pulp & paper, chemical processing, and power plants.

Design & Construction

● Body Material: High-grade cast iron (GG25/EN-JL1040) with corrosion-resistant epoxy coating (optional: polyurethane or Xylan coating for aggressive environments).

● Blade: Precision-machined stainless steel (SS304/SS316) with a sharp, beveled edge for smooth cutting of fibrous and particulate-laden fluids.

● Seat: Resilient EPDM/NBR (standard), with options for Viton, PTFE, or ultra-high-molecular-weight polyethylene (UHMWPE) for chemical resistance.

● Stem: Stainless steel (SS304/SS316) with anti-blowout design for safety.

● Packing: Graphite-reinforced gland packing ensures leak-free operation under high-pressure cycling.

Electric Actuator Specifications

● Type: Multi-turn electric actuator (on/off or modulating control).

● Voltage Options: 24V DC, 110V AC, 220V AC, 380V AC (other voltages available upon request).

● Control Signal: 4-20mA, PROFIBUS, Modbus RTU, or HART protocol for seamless integration into SCADA/DCS systems.

● Torque Output: Adjustable torque settings to prevent valve damage.

● Protection Class: IP67/IP68 (waterproof and dustproof), explosion-proof versions (ATEX/IECEx) available.

● Manual Override: Integrated handwheel for emergency operation during power failure.

Performance & Technical Data

● Size Range: DN200 (8") – other sizes (DN50 to DN1200) available.

● Pressure Rating: PN10/PN16 (150 psi) standard; higher ratings (PN25/PN40) upon request.

● Temperature Range: -20°C to +120°C (standard seat); -40°C to +200°C with high-temperature materials.

● Flow Direction: Bi-directional (recommended flow direction marked on valve body).

● Leakage Class: Zero leakage (Class VI per EN 12266-1) for bubble-tight shut-off.

Connection & Mounting

● Flange Standard: EN 1092-2 (PN16), ANSI B16.1 (Class 125/250), AS4087 (waterworks), or AWWA C509 (custom flanges available).

● Face-to-Face Dimensions: Complies with ISO 5752 (EN 558 Series 20) for easy replacement.

● Actuator Mounting: ISO 5211 compliant for quick actuator interchangeability.

Applications

Slurry & Abrasive Media Handling – Mining, dredging, tailings.

Wastewater & Sewage Treatment – Primary/secondary settling, sludge control.

Pulp & Paper Industry – Stock flow regulation, reject handling.

Chemical & Petrochemical – Acid/alkali slurry isolation.

Power Plants – Fly ash, bottom ash transport systems.

Features & Advantages

Heavy-Duty Construction – Reinforced body design for long service life in abrasive conditions.

Low Operating Torque – Energy-efficient electric actuator reduces power consumption.

Fail-Safe Options – Spring-return actuators for open/close fail-safe positions.

Easy Maintenance – Top-entry design allows seat and blade replacement without removing the valve from the pipeline.

Anti-Cavitation Design – Optimized flow path minimizes turbulence and vibration.

Certifications & Compliance

● ISO 9001:2015 – Quality management system certified.

● CE, RoHS, REACH – Compliant with EU directives.

● AWWA C517 – Meets waterworks standards (optional).

● ATEX/IECEx – Available for hazardous area installations.

Optional Accessories

● Limit switches & position transmitters (for remote indication).

● Heating jackets (for freeze protection in cold climates).

● Positioner & smart controller (for precise flow modulation).

● Locking device (for safety in high-vibration environments).

Why Choose WIVO VALVES?

◆ 30+ Years of Valve Manufacturing Expertise

◆ Custom Engineering Solutions (special materials, sizes, and actuation).

◆ Global Supply & After-Sales Support

◆ Competitive Lead Times & OEM/ODM Services


Contact WIVO VALVES Today for Quotations, CAD Drawings & Technical Support!


Whatsapp:+86-15963008926

Email:peter@wovalves.com

Tel:+86-17657183695
